China factory manufacture pcb rigid flex board for mobile phone camera pcb x ray machine
- $3.00 / 8 - 14 pieces
$1.00 / >=15 pieces - 8 pieces
- Guangzhou E-sun Technology Co.,Ltd.
- Guangdong, China
- Mr Ethan Lau
PRODUCT DETAIL
| Plate thickness: | 0.07-0.5MM | port: | Guangzhou Whampoa |
| Minute line spacing: | 0.04MM | Package preview: | |
| place of origin; place of origin: | Guangdong, China | Packaging Details: | carton; |
| Plate thickness: | 0.6mm | Board Dimensions: | 2.5kg/500pcs |
| color: | Green solder mask | Copper thickness: | 1oz / 1/2oz/ 1/3oz, 1OZ |
| Minute line width: | 0.04MM | Material: | FR-4 and polyimide |
| Layers: | 2 layer | MOQ: | 10 |
| Surface treatment: | HASL / OSP / ENIG / Immersion Silver / Tin / Nickel, ENIG | type: | hard Board |
| model: | esun-xraypcb | Design Manufacturer: | Yes |
| payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram | Minute Hole Size: | 0.1MM |
| chip: | Yes | Supply capacity: | 100000 pieces per month |
| Substrate: | polyimide/polyester | brand: | Yi Shun |
PCB capacity and technical specifications | ||
Floor | 1, 2, 4, 6 floors, up to 24 floors | |
Material | FR-4, High Tg, Isola, Aluminum, Rogers, etc. | |
PCB type | flexible | |
shape | Rectangular, circular, grooved, hollowed out, complex, irregular | |
Maximum printed circuit board size | 1200mm*600mm | |
thickness | 0.2~4.0mm, flexible 0.01~0.25'' | |
Thickness Tolerance | <10% | |
copper thickness | 0.5-6 oz | |
Copper Thickness Tolerance | <0.25oz | |
surface finish | HASL, LF HASL, Imm Gold, Imm Silver, OSP etc. | |
Solder mask | Green, red, white, yellow, blue, black, orange, purple | |
silk screen | white, black | |
Screen printing minimum line width | 0.006 inches or 0.15 mm | |
Minimum drilling diameter | 0.01'', 0.1mm or 10 million | |
Minimum trace/clearance | 0.075 mm or 3 million | |
PCB cutting | cut, V-score, tab-routed | |
