Fully automatic custom chemical stainless steel stirred tank reactor
- $7500.00 /set
- 1 set
- Zhejiang Shuangzi Intelligent Equipment Co., Ltd.
- Zhejiang, China
- Ms Alice Wang
PRODUCT DETAIL
| Material: | SUS304/SUS316L | place of origin; place of origin: | Zhejiang, China |
| capacity: | 5000L, 5000L | Seal type: | Machinery Seal |
| State of health: | new | Applicable industries: | Manufacturing plants, food and beverage plants |
| Marketing Type: | New Products 2020 | Agitator shaft: | frame type |
| Automatic level: | automatic | Showroom location: | United States |
| payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram | usage: | Induction Furnace Reactor |
| Supply capacity: | 600 sets per year | strength: | 5.5kw |
| port: | Ningbo or Shanghai port | Voltage: | customized |
| Core component warranty: | 1 year | product name: | Stainless Steel Chemical Reactor |
| Packaging Details: | Plywood enclosure or naked wrap | weight: | 5000 |
| Mechanical test report: | if | Package preview: | |
| brand: | sun | Main selling points: | easy to operate |
| way to heat up: | steam | Warranty: | 1 year |
| Video shipment inspection: | if | Types of: | tank reactor |
| Core components: | Programmable Controllers | After-sales service provided: | On-site installation, commissioning and training |
| Certification: | ASME certificate | Features: | reaction |
| Dimensions (L*W*H): | 2050*2050*4200mm |
Product Description
ThisFully automatic custom chemical stainless steel stirred tank reactorSuitable for reactions in the chemical industry and pharmaceuticals. The reactor body can be equipped with honeycomb jacket, pipe jacket or overall jacket structure, and can also be heated and cooled. The inner surface is polished by electrolytic mirror, the sealing head is processed by molding or spinning machine, and the nozzle and dead angle are transitioned by R angle. All components are processed in accordance with GMP standards. Agitator styles are anchor, round, frame and turbine. Rotating machinery can use cycloidal reducer or stepless reducer. The sealing device is a mechanical seal. Heating or cooling can be nested, half-pipe or partitioned. The heating method can adopt steam heating, electric heating and heat conduction oil to meet the needs of various working environments such as acidity, high temperature, wear and corrosion. Acid resistance, high temperature resistance, wear resistance and corrosion resistance.
Application and structure:
ThisFully automatic custom chemical stainless steel stirred tank reactor It can be used as a sterilizer in the fields of medicine, chemical industry and bioengineering. This equipment is mainly composed of a tank body, an overall jacket and an outer cladding, and the insulation material is between the outer cladding and the jacket. It has a stirrer on top of the reactor.
Parameter/Model | LP300 | LP400 | LP500 | LP600 | LP1000 | LP2000 | LP3000 | LP5000 | LP10000 | ||||||||
Capacity (L) | 300 | 400 | 500 | 600 | 1000 | 2000 | 3000 | 5000 | 10000 | ||||||||
Working pressure (inner layer) | ≦0.6Mpa | ||||||||||||||||
Working pressure (jacket layer) | ≦0.8Mpa | ||||||||||||||||
Motor power (kw) | 1.1 | 1.5 | 2.2 | 2.2 | 3 | 3 | 3 | 5.5 | 7.5 | ||||||||
stirring speed | 0-200 rpm | ||||||||||||||||
size | 900* 2200 | 1000*2200 | 1150*2400 | 1150*2500 | 1400* 2700 | 1580* 3000 | 1580* 3300 | 2050* 4200 | 2500* 5000 | ||||||||
heat transfer area | 2 | 2.4 | 2.7 | 3.1 | 4.5 | 7.5 | 7.5 | 10.4 | 20.2 | ||||||||
