Screen Printing Material Bolt Cloth Screen Printing Mesh
- $0.95 / >=5 meters
- 5 meters
- Shenze Jiamei Screen Printing Equipment Co., Ltd.
- Hebei, China
- Mr Victor Ying
PRODUCT DETAIL
| type: | Polyester mesh | Number of grids: | 18-420 mesh/inch |
| width: | 0.6-3.65m | brand: | Camry |
| Monofilament style: | Yes | elasticity: | High |
| payment terms: | L/C, T/T, Western Union, PayPal | model: | JM-03 |
| port: | Tianjin harbor | Supply capacity: | 10000 meters/month |
| Mesh opening: | 13%-65% | Material: | 100% polyester |
| Thread diameter: | 23-680 microns | thickness: | 46-490 microns |
| print: | screen printing | Weave Type: | clearly |
| color: | yellow | place of origin; place of origin: | Hebei china |
Product Description
Model | JM-03 |
Material | 100% polyester |
braided | plain weave |
mesh | 30-500 mesh/inch (13 T~165 T ) |
wire diameter | 27-200 microns |
aperture | 23-680 microns |
width | 1.27m, 1.65m, 1.83m, 2.30m, 3.30m, 3.60m, etc. |
color | white, yellow, etc. |
standard length | 50 m/roll |
Product Specifications
83 / 100 White 110 / 80 Yellow 110 / 80 White 156 / 64 Yellow 123 / 70 White 180 / 55 Yellow 137 / 64 White 195 / 55 Yellow 156 / 64 White 230 / 48 Yellow 180 / 55 White 255 / 40 Yellow 280 / 40 Yellow 305 / 34 Yellow 355 / 34 Yellow
Main features
• Low elasticity, high tension
• Accurate standard grid for uniformity
• Imported looms and materials
• Acid and alkali resistant
• Available in a variety of colors
• A variety of meshes are available, with filtering, waterproofing, and printing functions.
Choose the correct number of grids60 Mesh - The number of course meshes used for Glitter Inks. 86/90 Mesh - Recommended for printing opaque whites/lights on dark fabrics for maximum opacity. 110 Mesh - Recommended for general textile work, dark prints light, light dark prints. 125/160 Mesh - Recommended for general textile work, but with some finer detail/line work. 180/200 mesh - Textiles; smooth, lightweight fabrics, halftone, fair. 230/250 mesh - Textiles; very light material, graphic, general. 305/355 Mesh - Machining Jobs
Applications
Ceramic, PCB, Textile, Glass, Large Poster, Membrane Switch, Packaging, Screen, Image, Medical Device Printingand many more.
