high quality thickness 0.1mm 0.25mm 0.05mm astm b265 titanium sheet
- $34.00 / 1 - 9 kilograms
$26.00 / 10 - 49 kilograms
$18.00 / >=50 kilograms - 1 kilogram
- Baoji Dynamic Trading Co.,Ltd
- Shaanxi, China
- Mr Jim Zhang
| type: | Titanium foil titanium strip | application: | industrial |
| Material: | GR1,GR2,GR5,GR7,GR9,GR12 | density: | About 4.51g/cm3 |
| port: | Qingdao. Shanghai. Shenzhen Guangdong | surface: | Polishing, Pickling, Sandblasting |
| Processing service: | Cutting, bending, welding, uncoiling, cutting, punching | Advantage: | Corrosion resistance, high strength and light weight. |
| payment terms: | L/C,Western Union,D/P,D/A,T/T,MoneyGram | standard: | ASTM B265, AMS, ASTM 4911 |
| model: | Titanium foil | place of origin; place of origin: | Shaanxi |
| Titanium (min): | 99% | width: | 10~400mm |
| length: | 500-6000mm, cut as required | Supply capacity: | 10000 kg per month |
| grade: | GR1 GR2 GR5, GR1, GR2, GR5 | color: | primary color |
| brand: | Jimmy Cloud | Packaging Details: | Plywood shell, then tied with steel straps. Packaging will make the goods more secure when transported over long distances. |
| finishing: | Pickling, Machining, Sandblasting | Packaging Preview: | |
| product name: | Pure titanium grade 2 thin titanium foil |
♠Titanium foil is a titanium plate, strip, roll or sheet with a thickness of less than or equal to 0.1mm. The maximum width of rolled titanium foil is about 600mm.
♠The width of the titanium foil is cut according to the user's requirements. But the wider it is made, the higher the productivity.
♠Titanium foil is mainly used in aerospace, navigation, nuclear power, electronics, chemical industry, petroleum, precision manufacturing, medical and pharmaceutical fields.
| describe | Titanium foil/titanium tape |
| Material |
Gr1, Gr2, Gr3, Gr4, Gr5, Gr7, Gr6, Gr9, Gr11, Gr12, Gr16, Gr17, Gr25
TA0,TA1,TA2,TA5,TA6,TA7,TA9,TA10,TB2,TC1,TC2,TC3,TC4 |
| standard | ASTM B265, ASME SB265, DIN17851, TiA16Zr5Mo1.5, JIS4100-2007, GB3461-2007 |
| size |
Thickness: 0.01-2.0mm Width: 0.7-240mm Length: upon request |
| Minimum order quantity | 1kg/kg |
| equipment used | CNC lathes, milling machines, machining centers, thread rolling machines, magnetic needle polishing machines |
| feature |
1. High corrosion resistance 2. Low density 3. Non-ferromagnetic 4. Good biocompatibility |
| pack | Standard export packaging, suitable for various shipments, or as required. |
| application |
1. Based on high strength, the tensile strength of titanium products can reach 180Kg/mm². 2. Titanium and titanium alloys in the aviation industry are called "space metals"; in addition, In shipbuilding, chemical industry, manufacturing machine parts, Telecommunications equipment, cemented carbide and other applications are becoming more and more extensive 3. In addition, due to the good compatibility of titanium alloy with the human body, So titanium alloy can also be artificial bone. |
chemical composition:
| work(%) | C | n | iron | ○ | H | aluminum | five | titanium |
| GR1 | ≤0.08 | ≤0.03 | ≤0.20 | ≤0.18 |
≤0.015 |
- | - | Barr. |
| GR2 | ≤0.08 | ≤0.03 | ≤0.30 | ≤0.25 | ≤0.015 | - | - | Barr. |
| GR5 | ≤0.10 | ≤0.05 | ≤0.30 | ≤0.20 | ≤0.015 | 5.50-6.80 | 3.50-4.50 | Barr. |
Stretching Requirements:
| grade | tensile strength | Yield Strength 0.2% Offset | elongation at 2 in. or 50mm min.% |
Bending test | ||||||||
| sensitive | sensitive | sensitive | maximum | Less than 0.070" (1.8mm) thick | 0.070 to 0.187 inches (1.8 to 4.75mm) thickness |
|||||||
| Kersey | MPa | Kersey | MPa | Kersey | MPa | |||||||
| 1 | 35 | 240 | 20 | 138 | 45 | 310 | twenty four | 1.5T | 2T | |||
| 2 | 50 | 345 | 40 | 275 | 65 | 450 | 20 | 2T | 2.5T | |||
| 3 | 65 | 450 | 55 | 380 | 80 | 550 | 18 | 2T | 2.5T | |||
| 4 | 80 | 550 | 70 | 483 | 95 | 655 | 15 | 2.5T | 3T | |||
