10Mm 15Mm 25Mm 30Mm Long stroke DC 12v 24v miniature linear push-pull tubular solenoid
- $15.00 / 2 - 19 pieces
$12.00 / 20 - 199 pieces
$9.00 / 200 - 499 pieces
$4.00 / >=500 pieces - 2 pieces
- Zhongshan Landa Solenoid Co., Ltd.
- Guangdong, China
- Ms Miracle Wang
PRODUCT DETAIL
| brand: | Randa | Certificate: | ISO9001/ISO14001 |
| Packaging Details: | Product size: D25*L51 (mm) Carton size: 350*310*180 (mm) NW: 0.184 (KG) GW: 0.2 (KG) | application: | widely used |
| Key words: | Push-Pull Tubular Solenoid Valve | product name: | Push-Pull Tubular Solenoid |
| MOQ: | 2 | type: | push and pull |
| payment terms: | wire transfer | Supply capacity: | 50000 pieces per month |
| Origin: | China | Material: | steel |
| port: | Guangzhou/Shenzhen | model: | tubular |
| diameter: | Multiple models | Axis type: | round shaft |
| Voltage: | 12/24VDC |
10Mm 15Mm 25Mm 30Mm Long stroke DC 12v 24v miniature linear push-pull tubular solenoid
Product Description
| Specification | |||
| brand | Randa | product name | Tubular Push-Pull Solenoid |
| Model | TU2551 | Rated voltage | DC 12v 24v |
| strength | 8.5-85w | strength | 0-35N |
| waterproof level | IP65 | duty cycle | 10-100% |
| stroke | 0-10mm | Material | metal, electronic parts |
| form of action | push-pull | Weight (net weight) | 0.2 kg |
| installation method | tighten | Thread size and depth (mm) | / |
| Pressure test | AC 600V 50/60Hz 2s | insulation level | Second |
| packaging details | |||
| body size | L51*D25 (mm) | Carton size (standard) | 350*310*180(mm), accept customization |
feature
Tubular Solenoid Features
1. Push-pull type, linear motion, DC solenoid solenoid, supply return spring or plunger without return spring.
2. Tubular solenoids are ideal for locking solenoids, whether for doors, security or industrial machinery.
3. Typically used for longer strokes, can also be designed for high force heavy duty applications.
4. Single hole mounting hole, easy to install, can be customized as required.
Welcome to send inquiries to Lanta
