China Distillation Equipment Rotovap 5L 10L 20L 50L Vacuum Rotary Evaporator Price
- $560.00 / 1 - 2 units
$540.00 / >=3 units - 1 unit
- Henan Lanphan Industry Co., Ltd.
- Henan, China
- Ms Jingli Liu
PRODUCT DETAIL
| After-sales Service Provided: | Online support; | Core Components: | PLC,Engine,Motor; |
| Vacuum Display Mode: | Vacuum Meter; | Temperature Accuracy: | ±1℃; |
| Package Preview: | ; | Warranty of core components: | 1 Year; |
| After Warranty Service: | Video technical support,Online support; | Local Service Location: | United States; |
| Machinery Test Report: | Provided; | Voltage: | 220V/110V; |
| Lifting Distance: | 120mm; | Warranty: | 1 Year; |
| Brand Name: | Lanphan; | Name: | re-501 rotary evaporator; |
| Dimension(L*W*H): | 590*460*440mm; | Showroom Location: | United States; |
| Applicable Industries: | Manufacturing Plant,Food & Beverage Factory,Energy & Mining,Food & Beverage Shops; | Condition: | New; |
| Power: | 2KW; | Glass Material: | GG-17; |
| Video outgoing-inspection: | Provided; | Key Selling Points: | High Productivity; |
| Port: | Qing Dao, Tian Jin or as customer's demand; | Payment Terms: | Western Union,T/T; |
| Marketing Type: | Ordinary Product; | Weight: | 38; |
| Packaging Detail: | Re-501 Rotary Evaporator price: carton or wooden case package, customized package is available.; | Place of Origin: | Henan China; |
| Certification: | CE; | Supply Ability: | 3000 Unit/Units per Month; |
| Power Source: | Electric; | Rotating Speed: | 0-120rpm; |
| Process: | Drum Evaporator; |
Related Products
RE-1050 50L RE-501 5L RE-2000A 1L
Product Description
| Basic Parameter | Type | RE-501 |
| Glass Material | GG-17 | |
| Support Material | stainless steel | |
| Shell Material | Antisepsis Plastic Spraying 310*320*240mm | |
| Inner Container Material | stainless steel 280*170mm | |
| Baseboard Size | 350*330mm | |
| Volume of Rotary Bottle | 5L ¢50 flange aperture | |
| Volume of Recycling Bottle | 3L 35# ground aperture | |
| Vacuum Degree | 0.098Mpa | |
| Rotating Power | 40W | |
| Rotating Speed | 0-120rpm | |
| Heating Power | 2KW | |
| Temperature Control Range of Bath Kettle | 400°C | |
| Temperature Accuracy | ±1°C | |
| Voltage/Frequency (V/Hz) | 220V/50Hz | |
| Up and Down Distance | 120mm | |
| Shape Size(mm*mm*mm) | 700*335*1009mm | |
| Package Size(mm*mm*mm) | 1040*620*410 0.26 m³ | |
| Package Weight (KG) | 38 | |
| Function Allocation | Speed Adjustment Mode | Electrodeless Speed Regulation |
| Rotate Speed Display Mode | Digital Display | |
| Temperature Display Mode | Digital Display K Type Sensor | |
| Temperature Control Mode | Smart Temperature Control | |
| Sealing Mode | PTFE Sealing | |
| Condenser | Vertical Condenser 100*510mm 29#Standard Aperture | |
| Up and Down Mode | Manual Up and Down of Bath Kettle | |
| Continuous Charging | Standard Aperture Feeding Valve | |
| Vacuum Display Mode | Vacuum Meter | |
| Optional Equipping | Anti-splash Device | Equipping Transparent Cover of Bath Kettle |
| Anti-explosion | Anti-explosion Frequency Changer, Anti-explosion Dynamo EX40We | |
| Frame Part |
Plastic Spraying or PTFE Spraying |
|
| Our company's laboratory glass and laboratory instruments are independent research and development, available for custom-made according to client requirements. | ||
Packing List of 5l rotary evaporator manual
+
| Host | 1 | Rotary Bottle | 1 |
| Electric Cabinet | 1 | Recycling bottle | 1 |
| Aluminum Backing Ring of Special Sealing Ring | 1 | Condenser Pipe | 1 |
| Sealing Gasket | 1 | Suction Pipe | 1 |
| Protective Pipe 3A | 1 | Protective Pipe | 1 |
| Thermostat Water Bath Kettle | 1 | Special Components (additional Purchase) | 1 |
Application Field
Rotary evaporators are mainly used for concentration, crystallization, drying, separation and solvent recovery in medicine,
chemical and biochemical industries. Under the vacuum condition, the rotating flask is heated at a constant temperature, and can rotate at a constant speed. Then the material can form a large area of thin film in the inner wall of the flask, evaporating efficiently. The solvent steam can be cooled by efficient glass condenser and recycled in the receiving flask, greatly enhancing the evaporation efficiency.
