Customized Japan Technology HB20G Frukawa FXJ225 Excavator Hydraulic Rock Breaker Hammer Excavator Jack Hammer
- $1200.00 / 1 - 9 sets
$1000.00 / 10 - 99 sets
$800.00 / >=100 sets - 1 set
- Jiangsu Guchuan Machinery Co., Ltd.
- Jiangsu, China
- Mr Chris Zhao
PRODUCT DETAIL
| color: | black, yellow or customized | port: | Shanghai |
| Material: | 20 Chromium molybdenum | model: | HB20G |
| Package preview: | Mechanical test report: | if | |
| Impact rate (bpm): | 400-800 | Chisel diameter: | 135 mm |
| Oil flow (l/min): | 125-150 | Origin: | Jiangsu, China |
| weight: | 1830 kg | type: | top type |
| Showroom location: | not any | Packaging Details: | Wood packaging and external sealing |
| payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram, Google Pay and Paypal | brand: | good chance |
| pack: | wooden box | Purpose: | Construction/Mining/Demolition |
| Health status: | new | Applicable excavator (ton): | 18-26 years old |
| Applicable industries: | construction, mining, demolition | Core components: | pressure vessel |
| Video shipment inspection: | if | Supply capacity: | 50 sets per month |
| Working pressure(kg/cm2): | 160-180 | Marketing Type: | Hot Products of 2022 |
| MOQ: | 1 | Warranty: | 1 year |
GOOCHANCE hydraulic breaker 3 types:
>>>Side type:Wide range of uses including rock breaking, paving, building demolition and more.Side features:1. The overall length is shorter. 2. It is convenient to hang things. 3. Maintenance-free.>>>Top type:It is suitable for special operations with large elevation angles.Top features:1. Easy positioning and control; 2. More beneficial to excavators; 3. Lighter weight, less risk of drill pipe breakage>>> box/silent type:Low noise, energy saving and environmental protection.Box type/silent type features:1. Reduce noise and protect the environment. 2. The fully enclosed bracket protects the main body from damage. 3. Enhanced performance, productivity and durability.
Lightweight Hydraulic Breaker | ||||||||||||
model. | Chisel diameter (mm) | Excavator weight (tons) | Weight (kg) | Working flow (L/min) | Working pressure (bar) | Impact rate (bpm) | ||||||
SB10/GCB40 | 40 | 0.8-2.5 | 73 | 15-30 | 90-120 | 800-1400 | ||||||
SB20/GCB45 | 45 | 1.2-3.0 | 100 | 20-40 | 90-120 | 700-1200 | ||||||
SB30/GCB50 | 53 | 2.5-4.5 | 120 | 20-50 | 90-120 | 600-1100 | ||||||
SB40/GCB60 | 68 | 4.0-7.0 | 298 | 40-70 | 110-140 | 500-900 | ||||||
SB43/GCB75 | 75 | 6.0-9.0 | 375 | 50-90 | 120-150 | 400-800 | ||||||
SB45/GCB85 | 85 | 7.0-14 | 577 | 60-100 | 130-160 | 400-800 | ||||||
SB50/GCB100 | 100 | 11-16 | 890 | 80-110 | 150-170 | 350-700 | ||||||
MS250/R75 | 75 | 3-8 | 410 | 60-85 | 110-130 | 520-1000 | ||||||
Hydraulic breakers in the mid-weight range | ||||||||||||
SB70/GCB210 | 135 | 16-21 | 1515 | 100-150 | 160-180 | 350-600 | ||||||
SB81/GCB22O | 140 | 18-26 years old | 1754 | 120-180 | 160-180 | 350-500 | ||||||
SB81A/GCB220 | 140 | 18-26 years old | 1773 | 120-180 | 160-180 | 350-500 | ||||||
HB20G/GCB200 | 135 | 18-25 | 1680 | 125-150 | 160-180 | 400-800 | ||||||
MB1500/NB1500 | 135 | 18-25 | 1500 | 120-155 | 160-180 | 400-800 | ||||||
Large weight Rahydraulic breaker | ||||||||||||
SB121/GCB320 | 155 | 28-35 | 2555 | 180-240 | 160-180 | 300-450 | ||||||
SB131/GCB350 | 165 | 35-43 | 3065 | 200-260 | 160-180 | 250-400 | ||||||
SB151/GCB400 | 175 | 40-50 | 3909 | 210-290 | 160-180 | 200-350 | ||||||
HB30G/GCB300 | 150 | 25-30 | 2305 | 160-190 | 160-180 | 350-700 | ||||||
HB40G/GCB400 | 160 | 35-43 | 2781 | 190-250 | 160-180 | 250-400 | ||||||
GCB500 | 195 | 50-60 | 5350 | 245-290 | 230-250 | 100-150 | ||||||
GCB550 | 200 | 50-65 years old | 5500 | 255-300 | 240-260 | 100-150 | ||||||
GCB650 | 210 | 65-100 | 7200 | 290-340 | 250-270 | 90-130 | ||||||
Advantages of Goochance Hydraulic Breaker
▶powerful performance
Goochance hydraulic breakers are lighter, stronger and more powerful than ever.
▶ Adjustable frequency
Goochance hydraulic breaker intelligently selects the most economical striking frequency, improves production efficiency, does not waste energy, and ensures the best power recovery for the next blow,And can cope with various working conditions.
▶ Easy maintenance
Everything has been designed so that maintenance is no longer a chore.
▶easy to use
Goochance hydraulic breakers allow the operator to focus on the operation monitoring hydraulic parameters or power settings.
▶ Engineering and Innovation
From machining to final assembly, Goochance hydraulic breakers are manufactured using world-class technology, top-quality raw materials and the finest steel to provide the highest quality and reliability.
▶ Optimum lubrication system
Goochance hydraulic breakers offer a lubrication unit so that the breaker always receives a better supply of grease.
application
1. Mining industry: mountains, mines, crushing, secondary crushing. 2. Dissatisfaction with metallurgy, slag cleaning, ladle furnace dismantling, and dismantling equipment infrastructure. 3. Railway: tunnel, bridge, mountain. 4. Highway: highway maintenance, cement pavement crushing, foundation excavation. 5. Municipal gardens: concrete crushing, water, electricity and gas engineering construction, old city renovation. 6. Construction: demolition of old buildings, broken reinforced concrete. 7. Hulls in mussels. 8. Others: breaking ice, breaking sand.
How to choose the right chisel
Jiangsu Guchuan Machinery Co., Ltd. was established in 2009. We have been committed to the development of hydraulic breakers for 13 years, serving the development of heavy equipment subsidiary industries. Goochance has grown into a global company targeting the Chinese domestic market and overseas markets.
Goochance hydraulic breakers are made from the highest quality steel manufactured. Also, we have been doing our best to increase customer satisfaction through constant contact with our customers. In addition, our mass production and stocking of the best materials enables us to establish a quick supply system for our customers, resulting in higher price competitiveness than other companies.
In order to provide customers with the best products and services, Goochance is committed to the constant pursuit of novelty and never stops challenging and innovating. We always take "quality is our life" as our goal.
Goochance hydraulic breakers are made from the highest quality steel manufactured. Also, we have been doing our best to increase customer satisfaction through constant contact with our customers. In addition, our mass production and stocking of the best materials enables us to establish a quick supply system for our customers, resulting in higher price competitiveness than other companies.
In order to provide customers with the best products and services, Goochance is committed to the constant pursuit of novelty and never stops challenging and innovating. We always take "quality is our life" as our goal.
➤own design and technology
➤best quality and service
➤global enterprise
➤Various model lineup
➤Excellent compressive strength
➤unrivaled sturdiness
Q: Are you a manufacturer? |
A: Yes, our factory was established in 2010. |
Q: Are you sure your product is suitable for my excavator? |
A: Our hydraulic breaker is suitable for most excavators. Show us your excavator model and we will confirm the solution. |
Q: How about your product warranty? |
A: 12 months warranty for hydraulic breaker, 6 months warranty for spare parts. |
Q: Can you produce according to customer's design? |
A: Of course, OEM and ODM services are available. We are a professional manufacturer in Jiangsu. |
Q: What's the MOQ and payment terms? |
A: The MOQ of hydraulic breaker is 1 set. Payment by T/T, accept Western Union, our terms can be negotiated. |
Q: How about the delivery term? |
A: 5-25 working days after payment. |
Q: How about the package? |
A: Our hydraulic breakers are wrapped with stretch film, packed in pallets or glued wooden cases, or packed as required. |
Q: Which country do you export? |
A: Saudi Arabia, Korea, Thailand, Cyprus, India, Canada, Australia, Peru, Egypt, Brazil, Mexico, South Africa, etc. |
