DL32D FAA L 810 LED Building Dual Aircraft Warning Lights, 48v LED Obstruction Lights

PRODUCT DETAIL

Packaging Details:	1 carton: 484222cm / 4kg 4 cartons: 494379cm / 18kg	type:	Aviation obstruction lights
brand:	blue star	Supported dimmers:	No
Color temperature (CCT):	other	Certification:	ce
Warranty (year):	5 years	Lifespan (hours):	1000000
payment terms:	L/C, Western Union, T/T, Paypal	light source:	to lead
Light body material:	die cast aluminum	Beam Angle(°):	360 degree horizontal beam angle
Protection class:	IP67	Origin:	China Shanghai
Input voltage (V):	85-265VAC, 50/60 Hz; 12VDC; 24VDC; 30-60VDC;	Luminous color:	Red
Supply capacity:	2000 pieces per month	Lighting Solutions Services:	Lighting and Circuit Design
port:	Shanghai port

DL32D FAA L 810 LED Dual Aircraft Warning Light

Specification:

light output	DL32DST (double)	DL32DSS (Dual)
effective strength	32.5 candela	32.5 candela
vertical divergence	10 degrees
horizontal output	360 degrees
LED color	Red
LED lifetime	100,000 hours
Operation
flash pattern	Steady burning (default) or flashing mode (20-60 times/min)
energy consumption	5W (constantly bright)
power supply
Input voltage	85-265VAC, 50/60 Hz; 12VDC; 24VDC; 30-60VDC;
Mechanical structure
lens	Polycarbonate, UV stabilized
Body	die cast aluminum
waterproof	IP67
weight	3.5 kg	3.5KG
aspect	340mmx413mmx140mm	340mmx413mmx140mm
installation size	Threaded 3/4'' Bottom Hub
temperature range	-40℃ ~ +55℃
Relative humidity	100% condensing
wind speed	Up to 150 mph (240 km/h)
Warranty	5 years
Elective	Provides blinking mode (40FPM) Provides built-in photocell Provides built-in alarm relay contacts
