FFKM perfluororubber material high temperature resistant unvulcanized raw rubber
- $1300.00 / 1 - 9 kilograms
$1200.00 / 10 - 49 kilograms
$1100.00 / >=50 kilograms - 1 kilogram
- Sichuan Fudi New Energy Co., Ltd.
- Sichuan, China
- Ms Doris Xie
PRODUCT DETAIL
| model: | FD PF3000 | payment terms: | wire transfer |
| brand: | Fudi | Origin: | Sichuan, China |
| Supply capacity: | 100 kg per month | Certificate: | ISO 9001 |
| Packaging Details: | 1kg/bag 20kg/box | color: | custom made |
| Name: | FFKM Raw Gum | MOQ: | 500 g |
| port: | Shanghai, Shenzhen | Package preview: |
Product Description
Perfluoroelastomer (FFKM)It is the most resistant perfluoroelastomer in extreme environments. FFKM contains 70-76% fluorine, which helps FFKM work between -30 and 290 °C and can survive transient 330 °C operating environments well. FFKM is designed for the harshest conditions such as hot acids, bases, esters, ketones, alcohols and fuels; this has led to its application in the semiconductor, fuel and aerospace industries.
FD PF series FFKMOffer a competitive price as an alternativeDuPont® Kalrez®and Solvay® Tecnoflon®.
FD PF3030 | FD PF3060 | FD PF3090 | ||||
Mooney viscosity ML(1+10)121ºC | 15~45 years old | 46~75 years old | 76~120 | |||
Density 23ºC (g/cm³) | 2.04 | 2.04 | 2.04 | |||
MDR 15 minutes, 170 °C 0.5° arc | ||||||
Minimum torque(N*m) | 0.7 | 0.9 | 1.5 | |||
Maximum torque(N*m) | 26.3 | 27.5 | 28.6 | |||
Ts2 | 1'10'' | 1′13″ | 1′20″ | |||
T90 | 6′40″ | 6′43″ | 6′52″ | |||
Pressure cure: 170 °C for 10 minutes, post cure: 230 °C for 24 hours | ||||||
Tensile strength (Mpa) | 15.9 | 16.1 | 17 | |||
Elongation at break (%) | 163 | 171 | 178 | |||
Shore A Hardness | 72±2 | 73±2 | 74±2 | |||
Compression set (%) 200ºC 70H compression rate 25% | 38 | 36 | 35 | |||
Please contact our customer service for detailed specifications
E-mail: [email protected]
application
Due to the excellent performance of FKM, it is widely used in different fields, including:
* Chemical processes and petroleum refining, where they are used in seals, pumps, gaskets, etc. due to their resistance to chemicals;
* Analytical and process instruments: diaphragms, cylindrical fittings, ferrules, gaskets, etc.
* Semiconductor manufacturing;
* Food and pharmaceuticals, because of their low degradability, are also in contact with liquids;
* Chemical processes and petroleum refining, where they are used in seals, pumps, gaskets, etc. due to their resistance to chemicals;
* Analytical and process instruments: diaphragms, cylindrical fittings, ferrules, gaskets, etc.
* Semiconductor manufacturing;
* Food and pharmaceuticals, because of their low degradability, are also in contact with liquids;
Advantage
FUDI has focused on fluorine material solutions for more than 20 years. Our products range from basic chemical materials to fluoro products such as FKM FVMQ FFKM PTFE HNBR AEM and various process chemicals.
We focus on continuous improvement in four areas to provide competitive products.
We focus on continuous improvement in four areas to provide competitive products.
About Fudi
Sichuan Fudi New Energy Co., Ltd. was established in 2001. Fudi has focused on fluorine material solutions for more than 20 years. Our products range from basic chemical materials to fluorine products such as FKM FVMQ FFKM PTFE HNBR AEM and various processing
Chemicals.
Our factory is located in Chengdu, Sichuan, China. Covering an area of more than 30000 square meters, with more than 50 technicians and experienced employees, we have a production capacity of 1000 tons of various fluorine materials.
Chemicals.
Our factory is located in Chengdu, Sichuan, China. Covering an area of more than 30000 square meters, with more than 50 technicians and experienced employees, we have a production capacity of 1000 tons of various fluorine materials.
