High Efficiency Natural Gypsum Calcining Grinding Machine Low Price Gypsum Powder Making Machine
- $16980.00 / 1 - 1 sets
$16800.00 / >=2 sets - 1 set
- Henan Turui Machinery Co., Ltd.
- Henan, China
- Ms hn turui
PRODUCT DETAIL
| Advantage: | high efficiency | port: | Qingdao, Tianjin, Shanghai or other required ports |
| Voltage: | according to local requirements. | Showroom location: | Philippines, Indonesia, Pakistan, Mexico, Russia, Korea, South Africa, Nigeria, Uzbekistan, Tajikistan |
| capacity: | 2.7-40 tons/hour | Mechanical test report: | if |
| Video outbound inspection: | if | Dimensions (L*W*H): | According to model |
| quality: | high level | Core components: | PLC, engine, bearing, gearbox, motor |
| color: | According to customer requirements | strength: | 200-800 kW |
| payment terms: | L/C, T/T | Main selling points: | high productivity |
| Core component warranty: | 1 year | use: | production of gypsum powder |
| raw material: | Gypsum, limestone, cement | application: | Production of gypsum powder, mining, quarries, chemicals |
| Packaging Details: | Standard export containers, bare metal, motors and small parts are all packed in wooden boxes. | type: | fully automatic |
| Origin: | Henan, China | product name: | Gypsum Calcination Plant |
| Marketing Type: | 2020 New Products | Warranty: | 1 year |
| Certification: | ISO9001:2008 | brand: | Turui |
| Install: | under technical guidance | Applicable industries: | Manufacturing plants, energy and mining |
| Health status: | new | weight: | 4500 kg |
| Supply capacity: | 5 sets per month according to your request |
Product Description
Gypsum powder production line:The gypsum powder production line uses natural gypsum as raw material, and is equipped with equalizing device, double-stage crushing system, apron conveyor, vertical mill, Raymond mill, gypsum boiling kiln, cooling machine, waste heat recovery system, etc. Fluidized kiln has the advantages of small size, simple structure, large output, small footprint, easy control, perfect gypsum microstructure, stable physical properties, and low operating cost, and has been widely used in my country. Together with our production line are sold to Thailand, Uzbekistan, Colombia and Mexico.Fuel type:coal, oil, natural gas or liquefied petroleum gas
application
Gypsum calcining process equipment production line - the latest Raymond mill, with its bear tooth transmission, internal oil lubrication system, curved air duct and other intellectual property rights, has become one of the most advanced mills in the world.
Widely used in cement, coal, power plant desulfurization, metallurgy, chemical industry, non-metallic minerals, building materials, ceramics and other industries.It can process limestone, calcite, barite, dolomite, potassium feldspar, bentonite, medical stone, phosphate rock, manganese ore, iron ore, quartz, activated carbon, carbon black, ceramics, coal and other materials.
work rules
The gypsum calcining process equipment production line system consists of mills, powder separators, fans, jaw crushers, vibrating feeders, hoppers, dust collectors, pipes, powder collectors, electric cabinets, motors, etc.
Large pieces of material are crushed to the required particle size by the jaw crusher, then lifted to the buffer hopper by the elevator, and then sent to the mill for grinding. The material is ground between the ring and the roller, and rises with the airflow, the particles that cannot pass through the separator fall down and grind again, and the rest are collected as finished products. The airflow passing through the separator will enter the blower for recovery, which is a closed system.
Technical Parameters
Specification | ||||||
Annual production capacity | Capacity per hour | Annual Gypsum Consumption | Calciner size | |||
20,000 tons | 2.7 tons | 24000 tons | 4.5×1.0×1.2 meters | |||
30,000 tons | 4.2 tons | 36000 tons | 4.5×1.2×1.4m | |||
50,000 tons | 6.9 tons | 60,000 tons | 4.5×1.4×1.6 meters | |||
60,000 tons | 8.3 tons | 72000 tons | 4.5×1.6×1.8 meters | |||
100,000 tons | 13.88 tons | 120,000 tons | 4.5×2.0×2.2 meters | |||
150,000 tons | 20.83 tons | 180,000 tons | 4.5×2.2×2.4m | |||
200,000 tons | 27.77 tons | 240,000 tons | 4.5×2.4×2.6 meters | |||
