High speed fabric sueding machine textile finishing machine
- $40000.00 / 1 - 998 sets
$30000.00 / >=999 sets - 1 set
- Haining Textile Machinery Co., Ltd.
- Zhejiang, China
- Mr brown sun
| feature: | Eliminates potential tension in fabrics | Core component warranty: | 1 year |
| Marketing Type: | Hot Products of 2021 | Core components: | Programmable controller, motor |
| product name: | Automatic cloth inspection machine | Suitable: | heavy fabric |
| port: | Shanghai | Automatic level: | automatic |
| Video outbound inspection: | not available | brand: | not any |
| Health status: | new | Mechanical test report: | if |
| Fabric Type: | Shrinkage | Function: | Commercial electric cloth roll inspection machine |
| Supply capacity: | 80 sets per month | Showroom location: | Egypt, Turkey, Vietnam, Brazil, Peru, Indonesia, Pakistan, India, Chile, Bangladesh, Uzbekistan, Malaysia, Morocco |
| Name: | Cloth inspection machine | After-sales service provided: | online support |
| Voltage: | 110-220 volts | payment terms: | L/C, T/T |
| weight: | 4500 kg | Origin: | Zhejiang, China |
| Warranty: | 12 months, 1 year | application: | textile industry |
| Production capacity: | 1 | Packaging Details: | packed in a wooden box |
| Dimensions (L*W*H): | 5100*5030*2625 | Key words: | Cloth Rolling Equipment |
| strength: | 33.5/41.5 | Applicable industries: | Hotels, Clothing Stores, Manufacturing Factories |
application
This machine is suitable for surface polishing of natural, chemical fiber, knitted and social fabrics. It is mainly used for the processing of ordinary woolen, blankets, ultra-fine velvet and knitting non-pressure velvet. It can also be used for polishing velvet, cotton fabrics, high-pile knitted fabrics, chemical fibers, etc. Its working efficiency is nearly twice that of ordinary polishing machines.
Specification
|
project |
data |
|
|
Nominal Width (mm) |
2000,2500 |
|
|
Polishing roller diameter (mm) |
370 |
|
|
Polishing roller speed (m/min) |
300-900 variable |
|
|
turn around |
forward, backward |
|
|
Maximum Polishing Temperature |
250°C |
|
|
Fabric speed(m/min) |
9-30 |
|
|
Heating power (kW) |
57.6 / 59.7 |
|
|
Heating power (kW) |
13.95 |
|
|
Dimensions |
length (mm) |
4330 |
|
|
Width (mm) |
4530/4730 |
|
|
Well) |
2750 |
Compared with similar machines, this high-quality MB431 polishing machine is easy to operate and reliable, with the following features:
1 single polishing roll double table lathe works well. The polishing roller can be reversed, anti-clockwise polishing pile, clockwise polishing velvet. The working temperature is 75~250°C, controlled by a professional temperature controller and displayed on the digital display device. The pneumatic device is used to automatically correct the deviation of the desktop lathe and the belt.
2. Adjust the speed of the front guide roller and the rear guide roller by exchanging the sprocket to control the feeding tension.
3. The fabric guide motor and output motor adopt frequency converters, and the fabric speed can be selected from 9 to 30m/min, which can be displayed on the digital display device and can be directly adjusted.
