Hose Clamp Manufacturer Premium Steel White OEM Cast Iron Hose Clamp Hanging Clamp Galvanized 24 Hours Online
- $0.38 / 2000 - 9999 pieces
$0.35 / >=10000 pieces - 2000 pieces
- Cixi Cobon Tool Co., Ltd.
- Zhejiang, China
- Ms Tina Ye
PRODUCT DETAIL
Pipe clamp type: | other | usage: | pipe clamp |
Finish: | galvanized, zinc | product name: | pipe clamp |
Packaging Preview: | Name: | cast iron pipe clamp | |
Packaging Details: | Big plastic bag, general export carton, wooden pallet | Function: | fixed tube |
size: | 1/2"- 8" | structure: | hanging clip |
color: | white | application: | construction area, general industry |
port: | Ningbo/Shanghai/Yiwu | Custom Support: | OEM |
Supply capacity: | 8 20ft containers per month | payment terms: | L/C,D/P,T/T |
Surface treatment: | Galvanized Color | measuring system: | Metric |
Warranty: | 24 hours online | Material: | steel |
Product Description
Product parameters
product name | pipe clamp |
Weld Nuts | Nut M8+10 |
place of origin; place of origin | Ningbo, China |
your face: | Galvanized |
color: | Plate multi-color plating |
application: | heating |
model: | M8+10 |
rubber | EPDM rubber |
Craft: | casting |
connect: | welding |
shape: | reduce |
measuring system: | inches, metric |
type: | saddle clip |
refer to | ØSIZEmm | D (range) mm | inch | screws on both sides |
147018 | 18 | 15-19 | 3/8" | M6*15 |
147022 | twenty two | 20-25 | 1/2" | M6*15 |
147028 | 28 | 26-30 | 3/4" | M6*15 |
147035 | 35 | 32-36 | 1" | M6*15 |
147040 | 40 | 38-43 | 11/4" | M6*15 |
147048 | 48 | 47-51 | 11/2" | M6*15 |
147054 | 54 | 53-58 | M6*15 | |
147060 | 60 | 60-64 | 2" | M6*15 |
147070 | 70 | 68-72 | M6*15 | |
147075 | 75 | 75-80 | 21/2" | M6*15 |
147083 | 83 | 80-86 | M6*20 | |
147090 | 90 | 87-92 | 3" | M6*20 |
147100 | 100 | 99-105 | 31/2" | M6*20 |
147110 | 110 | 107-112 | M6*20 | |
147115 | 115 | 113-118 | 4" | M6*20 |
147125 | 125 | 125-130 | M6*20 | |
147133 | 133 | 132-137 | M6*20 | |
147140 | 140 | 136-142 | 5" | M6*20 |
147160 | 160 | 159-166 | 6" | M6*20 |
147200 | 200 | 200-212 | M6*20 | |
147250 | 250 | 248-252 | M6*20 | |
147315 | 315 | 312-318 | M6*20 |
