Mining Shotcrete Robot Wet Shotcrete Machine Concrete Spraying Equipment
- $12000.00 /set
- 1 set
- Hunan NinthGift Technology Co., Ltd.
- Hunan, China
- Ms Alice Lu
PRODUCT DETAIL
| Warranty of core components: | 1 Year; | Rated Power((kW): | 75; |
| Core Components: | Engine; | Mode: | 4 cylinder liquid-cooled diesel engine; |
| Grade ability: | 30; | Air Consumption: | 60~720; |
| Weight: | 17ton,17 kg; | Supply Ability: | 100 Sets per Month; |
| Max Aggregate Size: | 16; | Power: | 75KW; |
| Theoretical pump capacity (m3/h): | 0-25; | Voltage: | 380; |
| Warranty: | 1 Year; | Video outgoing-inspection: | Provided; |
| UNIQUE SELLING POINT: | High operating efficiency; | Package Preview: | ; |
| Brand Name: | ZLCONN; | Outside dimension(L*W*H)(mm): | 8265*2500*3200; |
| Payment Terms: | T/T; | Ground clearance(mm): | 400; |
| Max. Conveying Distance: | 25; | Power Source(V/Hz): | 380/50; |
| Packaging Detail: | PALLET; | Hose Inner Diameter: | 80 mm; |
| Marketing Type: | New Product 2020; | Condition: | New; |
| Machinery Test Report: | Not Available; | Dimension(L*W*H): | 8265*2500*3200; |
| Travelling speed(km/h): | 0~15; | Applicable Industries: | Construction works ,Energy & Mining; |
| Max.wind flow(m3/min ): | 13.5; | Showroom Location: | None; |
| Port: | shenzhen , shanghai; | Place of Origin: | Hunan, China; |
Product Description
KC2512W Wet Shotcrete Machine
1.7-PRS Spraying Boom System
2.Wireless remote control, high accuracy, wide spray area, minimum spray rejection and low concentration of dust.
- Suitable to Railway Tunnel & Highway Tunnel
- long-reach spray boom allows to work at long distance and great height.
- 3-PRS spray head gives full spherical spray area without blind spot.
- Full hydraulic foldable & telescopic intelligent spray boom guarantees no interference when all boom sections working at the same.
- Minimum height and rotation radius, 4-wheel crab swing, suitable for space limited and complex conditions work sites.
- 4-wheel Drive & 4-wheel Steering Engineering Chassis
- Rigid chassis with floating front axle, internal combustion – hydrostatic transmission, 4-wheel drive, with functions of 4-wheel steering and 4-wheel crab .
- 4 hydraulic supporting leg hold the vehicle steady at all times, absorb forces when material blending, pumping and spraying.
- High Efficiency, Steady Concrete Delivery System
- Advanced Elec-hydraulic proportional hydraulic system and double pump double circuit hydraulic design, offers high pumping pressure and high efficiency, steady reversing and small impact. .
- Reliable Elec-hydraulic proportional control technology, achieving a wide range of pump output in 0-25m3/h, to meet the needs of different shotcrete conditions.
- Remote Control & PLC Electrical Control System
- Complete manual control on vehicle and compact full function wireless remote control; Protection of over voltage and low voltage; Double safety emergency stop
- Computerized man-machine communication module: Input and record spray operation data; display real time running condition and running data; failure report.
- Compact and sturdy wireless remote control offers unlimited movement control to the spray boom and nozzle operator.
- Intelligent Setting Accelerator Adding System
- Advanced & reliable ele-hydraulic proportional technology and PLC control, auto-achieving the speed change of setting pump, to adjust the output of setting pump in line with the same of concrete.
Our Services
- Wide-ranging Technical Services
- Supportive after-sales services
- Skillful technical service team
- Hold both theory training and on site training
