PowerMark Gold Equivalent THQL THQP Q Line Breaker Panel 2 4 6 8 12 20 Space SPN Distribution Board Main Lug Load Center
- $4.60 / >=100 pieces
- 100 pieces
- Shanghai Newtrend Electric Co., Ltd.
- Shanghai, China
- Mr Nick Zhu
| model: | TL | Main breaker: | 40A, 70A, 125A, 200A |
| color: | grey | port: | Shanghai |
| stage: | Simplex | current: | 40A/70A/125A/200A/225A |
| Number of spaces: | 2, 4, 6, 8, 12, 16, 20 | brand: | New Trend or OEM |
| Supply capacity: | 10000 pieces per month | Origin: | Zhejiang, China |
| Installable circuit breakers: | Q-Line Circuit Breakers | Packaging Details: | Standard export carton |
| Voltage: | 110/240V | payment terms: | wire transfer |
PowerMark Gold Equivalent THQL THQP Q Line Breaker Panel 2 4 6 8 12 20 Space SPN Distribution Board Main Lug Load Center
application:
Q-Line Circuit Breaker Load Centers are designed for the safe and reliable distribution and control of electrical power as service entrance devices for GE Q-Line Circuit Breaker residential, commercial and light industrial locations.
feature:
❖ Flush or surface or combination, single phase, 40-225A, 4-42 way.
❖ Compatible with GE Q-line circuit breakers, including GE 1/2" THQP circuit breakers.
❖ Suitable for AC 50/60Hz, rated voltage up to 110/240V, rated current 40A/70A/125A/200A/225A.
❖ Main lugs can be easily converted to main breakers (convertible)
♦ Made of high quality steel sheet and matte polyester powder coating.
❖ Indoor and outdoor rated enclosures
❖ Straight-through main wiring
| reference picture | main ampere score |
part number |
maximum space For 1'' circuit breaker |
maximum space For 1/2" circuit breaker |
shell type |
type | optional door | ||
| 1P | 2P | 1P | 2P | ||||||
 |
40A | TL240SCU | 2 | 1 | 4 | 1 | surface | main lug | - |
| 70A | TL270SCU | 2 | 1 | 4 | 1 | surface | main lug | - | |
 |
125A | TL412C | 4 | 2 | 8 | 3 | combination | main lug | - |
 |
TL612FCU | 6 | 3 | 12 | 4 | rinse | main lug | - | |
| TL812FCU | 8 | 4 | 16 | 8 | rinse | main lug | - | ||
| TL612SCU | 6 | 3 | 12 | 4 | surface | main lug | - | ||
| TL812SCU | 8 | 4 | 16 | 8 | surface | main lug | - | ||
 |
TLM612FCU | 6 | 3 | 12 | 4 | rinse | convertible car | - | |
| TLM812FCU | 8 | 4 | 16 | 8 | rinse | convertible car | - | ||
| TLM612SCU | 6 | 3 | 12 | 4 | surface | convertible car | - | ||
| TLM812SCU | 8 | 4 | 16 | 8 | surface | convertible car | - | ||
 |
TL612FCUD | 6 | 3 | 12 | 4 | rinse | main lug | with optional door | |
| TL812FCUD | 8 | 4 | 16 | 8 | rinse | main lug | with optional door | ||
| TL612 Scud | 6 | 3 | 12 | 4 | surface | main lug | with optional door | ||
| TL812 Scud | 8 | 4 | 16 | 8 | surface | main lug | with optional door | ||
 |
TLM612FCUD | 6 | 3 | 12 | 4 | rinse | convertible car | with optional door | |
| TLM812FCUD | 8 | 4 | 16 | 8 | rinse | convertible car | with optional door | ||
| TLM612 Scud | 6 | 3 | 12 | 4 | surface | convertible car | with optional door | ||
| TLM812 Scud | 8 | 4 | 16 | 8 | surface | convertible car | with optional door | ||
 |
TLM1212CCU | 12 | 6 | twenty four | 10 | combination | convertible car | - | |
 |
200A | TLM1620CCU | 16 | 8 | 32 | 14 | combination | convertible car | - |
| TLM2020CCU | 20 | 10 | 40 | 18 | combination | convertible car | - | ||
