Automatic High Speed Solar Cell Laser Etching Machine
- $30000.00 / 1 - 2 sets
$2700.00 / 3 - 8 sets
$2400.00 / >=9 sets - 1 set
- Jinan Artech Machinery Co., Ltd.
- Shandong, China
- Mr Leon Xu
| Weight (kg): | 600 kg | brand: | Yatai CBC |
| controlling software: | automatic | payment terms: | L/C, T/T |
| application: | laser scribing | Certification: | ce |
| port: | any port in China | Supported graphic formats: | DXF format |
| Main selling points: | flexible manufacturing | Supply capacity: | 20 sets per month |
| Local service location: | not any | Laser source brand: | Raycus |
| Packaging Details: | wooden box | Applicable industries: | manufacturing plant |
| After warranty service: | Video Technical Support | Warranty: | 2 years |
| Laser type: | fiber-optic laser | Applicable materials: | Monocrystalline silicon, polycrystalline silicon and solar cells |
| Rail brand: | Shangyin | Showroom location: | not any |
| Origin: | Shandong China | cooling method: | air cooled |
| Control system brand: | ARTECH CNC | After-sales service provided: | online support |
| CNC or not: | Yes | Laser head brand: | Yatek |
| Health status: | new |
1. Equipment introduction
It is suitable for laser scribing of monocrystalline silicon, polycrystalline silicon, and solar cells, and can realize functions such as automatic loading, cell positioning, laser scribing, and robotic arm loading and unloading. Professional control software, maintenance-free, easy to operate.
2. Technical parameters
Model | SFS-30AD |
laser power | 30W |
Laser wavelength | 1064nm |
Scribing speed | Maximum 600mm/s |
Line Width | ≤40μm |
Scribing Depth | 20-120μm; (adjustment) |
Marking accuracy | ±0.1mm |
Targeting | mechanical positioning |
Dicing ability | 2000 full batteries/hour |
damage rate | ≤0.15% |
Solar Cell Specifications | 156×156-158×158mm |
size | 1260×760×1600 |
net weight | 0.6 tons |
3. Equipment Features
Advanced scribing technology:
Raycus laser source is used, the laser beam quality is good, the laser scribing line is fine, the cell cutting surface is more uniform, the cell damage is small, and the cutting accuracy is high.
high efficiency
The laser scribing speed is fast, and the production capacity can reach 2000 full cells/hour
precise positioning
Fully automatic positioning of solar cells, positioning accuracy ≤ ± 0.1mm
high degree of automation
Automatic loading and unloading, automatic positioning and automatic scribing of solar cells. Stable performance, low failure rate, easy maintenance.
.
