Factory Sales Cem-1 Copper Clad Laminate Sheet FR4/ CEM-1/ CEM-3/FR1/ AL CCL For Pcb Use

PRODUCT DETAIL
Payment Terms:L/C,Western Union,D/P,D/A,T/T,MoneyGram;Min. Line Spacing:0.1MM;
Type:Insulation Sheet;Brand Name:Shichao Electronics(SC);
Min. Line Width:3MIL;Board Size:1030X1230mm/1044X1245mm;
Copper Thickness:12μ/15μ/18μ/23μ/25μ;Base Material:The glass fiber;
Board Thickness:0.4/0.6/0.8//1.0/1.2/1./1.6/2.0mm;Place of Origin:Guangdong, China;
Model Number:CEM-CCL-A01;Supply Ability:1000000 Pieces per Month;
Surface Finishing:OSP/Lead-free tin/Pattern Gold Plating;Package Preview:;
Min. Hole Size:0.;Port:Guangzhou;
Quick Details
Place of Origin
Guangdong,CHina
Brand Name Shichao(sc)
Model Number fr4/xpc/fr1
Type Insulation Sheet
Material FiberGlass
Application High Voltage, Electronics Device
Rated Voltage 40KV
Tensile Strength ≥340MPa
Product name Flexible fr4 copper clad laminate sheet offcut
Key Words PCB,CCL
Service One-stop Service
Certificate ROHS
Trade Term FOB,CIF etc
Payment T/T,L/C,Western Union
Port Guangzhou
Market Global

Product description

XPC Copper clad laminated sheet/CCL consist of bleached wood pulp paper, impregnated with modified phenolic resin and clad with electrolytic copper foil.It has high dimension stability, good punching behavior at low temperature, high thermal resistance and are widely used for computers, telephones, Hi-Fi acoustic devices, electronic toys and etc.
Note:Different thickness copper foil in one side or double sides can be supplied. 18um,25um,35um,70um

Relevant product parameters
Cooper clad laminate

AL CCL
FR-4
FR-1
CEM-1
XPC
Base material
aluminum
fiberglass
fiberglass
paper+fiber glass
paper
Color
blue film
green film
light green,yellow
brown
yellow+white
brown
Copper foil
single or double side:18,25,35,70 micron
single side:18,25,35,70  micron
Sheet thickness
0.4-2mm

Size
1000*1200mm
500*600mm
1000*600mm
500*1200mm

40''*48'' , 41''*49'' , 43''*49''


41''*49''

FAQ
Q:What about the package of product? A:1. Wooden pallet with carton. 2. Plastic pallet with carton. 3. Wooden wooden pallet with wooden case. 4. According to . . customer requirements.
Q:What's the payment? A:30%TT advance , 70% after send the copy of the BL.We accept T/T,L/C, Western Union ,USD.
Q:If I need sample,what should I do? A:It's our pleasure to send sample for you.You can send me your delivery address by email or message.We will send you . . . free sample at first time.
Q:Can you give me a discount price? A:It is depending on the volume. The larger the volume is, the more discount you can enjoy.
Q:Why is your price a bit higher than other Chinese suppliers? A:To meet the requirement of different customers and areas, our factory manufactures various kinds of quality for each . . . item at a wide range of price. We can offer the products of different quality levels depending on customer’s target price and quality requirement.
Q:How can you guarantee the quality of mass production is same with the sample sent to me before? A:Our warehouse staff will leave another same sample in our company, with your company name marked on it, which our production will be based on.
Q:How can you deal with quality issues that customer feedback after receiving the goods? A:1) Customers take photos of unqualified goods and then our sales staff will send them to Engineering Department to . verify.
2) If the issue is confirmed, our sales staff will explain the root cause and take corrective actions in coming orders.
3) Finally, we will negotiate with our customers to make some compensation.
