LHD Technology Professional Pcb Pcb High Frequency PCB Manufacturer
- $1.00 / 1 - 99 pieces
$0.60 / 100 - 999 pieces
$0.30 / 1000 - 9999 pieces
$0.10 / >=10000 pieces - 1 piece
- Huizhou Linghangda Technology Co., Ltd.
- GuangDong, China
- Mr Alan Liu
PRODUCT DETAIL
| type: | High frequency circuit board | payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram |
| Substrate: | FR-4/CEM-1/CEM-3/Polyimild/PTFE/Rogers | Spray flux: | Add on |
| Maximum board size: | 457 * 356 (18'' * 14'') | Surface treatment: | HASL/OSP/Ag/ENIG/ENEPIG/Immersion Silver/Tin |
| Plate thickness: | 0.2-6mm | Minute Hole Size: | 0.1mm(4mil) for HDI / 0.15mm(6mil) |
| quality assurance: | AOI IQC PQC QA | Supply capacity: | 70000 square meters per month |
| Copper thickness: | 0.4-2mil (10-50um) | brand: | scraper technology |
| Packaging Details: | PCBA Gibson vacuum packaging or anti-static packaging Outer packaging: export carton or according to customer requirements. | capacity: | 70 million impressions per month |
| Minute line spacing: | 0.003'' | Package preview: | |
| model: | Custom PCB and PCB Assembly | Wave soldering: | 2 |
| Maximum plate width: | 400mm | Board Dimensions: | custom |
| Minute line width: | 0.075mm/0.075mm(3mil/3mil) | Biggest temper: | 399 degrees Celsius |
| product name: | circuit board | port: | Shenzhen Guangzhou Hong Kong |
| Application fields: | Automotive, medical, industrial, IOT, smart home, security equipment, | speed: | 0.15 seconds/chip, 0.7 seconds/QFR |
| Origin: | Guangdong, China |
Oem Electronic Pcba Manufacturing Smt Professional Custom Pcba Design Circuit Board Prototype Assembly Service Supplier
the banner
Product Description
PCB manufacturing specification
| project | parameter |
| double sided/multilayer | |
| Maximum panel size | 32'*20'(800mm*508mm) |
| Minimum track/clearance IL | 0.075mm/0.075mm(3mil/3mil) |
| Minimum hole ring on inner side | 3 million (0.075mm) |
| Maximum Copper Weight OL | 6oz(210um) |
| Maximum copper weight 1L | 12oz(420um) |
| Finished plate thickness | 0.20-6mm |
| layers | 2-32L |
| layer-to-layer registration | ±3mil(±76um) |
| Minimum Finished Aperture | 0.15mm(6mil), 0.1mm(4mil) for HDI |
| Hole position accuracy | ±2mil(±50um) |
| Slot tolerance | ±3mil(±75um) |
| PTH Diameter Tolerance | ±2mil(±50um) |
| NPTH Diameter Tolerance | ±1mil(25±um) |
| Maximum aspect ratio PTH | 10:1 |
| copper on hole wall | 0.4-2mil (10-50um) |
| Graphic Registration Tolerance | ±3mil(0.075um) |
| Minimum track/clearance 1L(mil) - depends on copper weight | 3 million/3 million (75 micron/75 micron) |
| Track etch tolerance | ±1mil(±25um) |
