USB NFC Reader D16
- $31.30 /unit
- 1 unit
- Shenzhen E-Card One Technology Co., Ltd.
- Guangdong, China
- Ms Ellen Wang
PRODUCT DETAIL
| API: | Support PC/SC Support CT-API | Supply capacity: | 3000 pieces per month |
| Reading distance: | up to 25 mm | Packaging Details: | Neutral packaging or packaging according to customer requirements. |
| brand: | An e-card | protocol: | ISO 14443A |
| Origin: | Guangdong, China | Built-in peripherals: | Two user-controllable bi-color LEDs |
| The driver is compatible with: | Linux and Mac OS | NFC support: | Reader/Writer Mode |
| payment terms: | Western Union, T/T | color: | white |
| interface: | USB 2.0 Full Speed BT 4.0 Smart | Compatible systems: | Windows PC/SC and CCID |
| frequency: | 13.56Mhz |
Product Description
Secure BT NFC Reader
ACR1311U-N2 Bluetooth® NFC Reader combines the latest 13.56 MHz contactless technology and
Bluetooth® Smart connectivity for mobile smart cards and NFC applications.
Supports ISO 14443 Part 4 Type A cards, MIFARE and MIFARE DESFire. This makes it an ideal device for a wide range of applications
A range of solutions such as hands-free verification of physical and logical access control, and inventory tracking. ACR1311U-N2 has a Bluetooth 4.0 interface for pairing with mobile devices and a USB full-speed interface for tethered operation. Additionally, it can read/write contactless smart cards and NFC device access at speeds up to 424 Kbps.
Bluetooth® Smart connectivity for mobile smart cards and NFC applications.
Supports ISO 14443 Part 4 Type A cards, MIFARE and MIFARE DESFire. This makes it an ideal device for a wide range of applications
A range of solutions such as hands-free verification of physical and logical access control, and inventory tracking. ACR1311U-N2 has a Bluetooth 4.0 interface for pairing with mobile devices and a USB full-speed interface for tethered operation. Additionally, it can read/write contactless smart cards and NFC device access at speeds up to 424 Kbps.
Specification
feature
Support for contactless smart cards:
* Built-in antenna for contactless tag access, read distance up to 25 mm
(depending on label type)
* Supports ISO 14443 Part 4 Type A cards
* Support MIFARE and MIFARE DESFire
* Built-in anti-collision function (only one tag can be accessed at any time)
* NFC support:Reader/Writer Mode
USB 2.0 full speed interface
Bluetooth 4.0 smart interface
Plug and play – CCID support for maximum mobility
USB firmware upgrade capability
Compliance with standards and certifications.
¡ EN60950/IEC60950
¡ ISO 14443
¡ Bluetooth® Smart
¡ RoHS.
¡ PC/SC
I'm Sadie
* Built-in antenna for contactless tag access, read distance up to 25 mm
(depending on label type)
* Supports ISO 14443 Part 4 Type A cards
* Support MIFARE and MIFARE DESFire
* Built-in anti-collision function (only one tag can be accessed at any time)
* NFC support:Reader/Writer Mode
USB 2.0 full speed interface
Bluetooth 4.0 smart interface
Plug and play – CCID support for maximum mobility
USB firmware upgrade capability
Compliance with standards and certifications.
¡ EN60950/IEC60950
¡ ISO 14443
¡ Bluetooth® Smart
¡ RoHS.
¡ PC/SC
I'm Sadie
i arrived
IMicrosoft® WHQL
technical specifications
Universal Serial Bus interface
E-government
Electronic medical
cyber security
Access control
Wallet and Loyalty
public key infrastructure
bluetooth interface
Type: BT Low Power 4.0 Single Mode
Contactless Smart Card Interface
Standards: ISO 14443 A & B Parts 1-4, ISO18092
Protocol: ISO14443 T=CL for ISO14443-4 compliant cards and
T=CL emulates MIFARE 1K/4K, ISO 18092 FelCa and NFC tags
Smart card read/write speeds: 106 kbps, 212 kbps, 424 kbps and 848 kbps
Frequency of operation for contactless card access
Operating frequency: 13.56MHz
Antenna: Operating distance up to 60 mm (depending on card type)
Operating conditions
Device Driver OS Support:
Windows® ME, Windows® 98, Windows® 2000, Windows® XP, Windows Vista®, Windows® 7, Windows® 8,
Windows® 8.1, Windows® 10, Windows® Server 2003, Windows® Server 2008, Windows® Server 2008 R2, Windows® Server 2012, Windows® Server 2012 R2
Linux®, Mac OS®, Android™1, iOS2
OEM : OEM-Logo possible, customer specific colors, housings and card connectors
E-government
Electronic medical
cyber security
Access control
Wallet and Loyalty
public key infrastructure
bluetooth interface
Type: BT Low Power 4.0 Single Mode
Contactless Smart Card Interface
Standards: ISO 14443 A & B Parts 1-4, ISO18092
Protocol: ISO14443 T=CL for ISO14443-4 compliant cards and
T=CL emulates MIFARE 1K/4K, ISO 18092 FelCa and NFC tags
Smart card read/write speeds: 106 kbps, 212 kbps, 424 kbps and 848 kbps
Frequency of operation for contactless card access
Operating frequency: 13.56MHz
Antenna: Operating distance up to 60 mm (depending on card type)
case
Dimensions: 60mm (L) × 47.98mm (W) × 12mm (H)
white color
Weight: 30g
Dimensions: 60mm (L) × 47.98mm (W) × 12mm (H)
white color
Weight: 30g
Operating conditions
Temperature: 0 - 50°C
Humidity: max. 90% (non-condensing)
Certification/Compliance: EN60950/IEC 60950, ISO 14443, USB Full Speed, Bluetooth Smart, PC/SC, CCID, RoHS 2, REACH, Microsoft®, WHQ
Humidity: max. 90% (non-condensing)
Certification/Compliance: EN60950/IEC 60950, ISO 14443, USB Full Speed, Bluetooth Smart, PC/SC, CCID, RoHS 2, REACH, Microsoft®, WHQ
Device Driver OS Support:
Windows® ME, Windows® 98, Windows® 2000, Windows® XP, Windows Vista®, Windows® 7, Windows® 8,
Windows® 8.1, Windows® 10, Windows® Server 2003, Windows® Server 2008, Windows® Server 2008 R2, Windows® Server 2012, Windows® Server 2012 R2
Linux®, Mac OS®, Android™1, iOS2
OEM : OEM-Logo possible, customer specific colors, housings and card connectors
